LT Switchboards & PanelsPCCMCC6300 A
LT Panels
Overview
Power and motor control centres built to your single-line diagram — Form 3b or Form 4 separation, type-tested, up to 6300 A.
Design envelope
- StandardIS/IEC 61439-1 & 61439-2
- Operational currentUp to 6300 A
- Form of separationForm 1 to Form 4b
- Degree of protectionIP42 to IP55
Built to order
7 panels
Every panel in the family.
Each one is fabricated to your single-line diagram and leaves the works with its ratings on the plate. Open a panel for what it does, what it's rated to and when to specify it.
PCC · 6300 A · Form 3b/4
Power Control Center
View more
MCC · 4000 A · Draw-out
Motor Control Center
View more
PMCC · Combined
Power cum Motor Control Center
View more
Chiller · AHU · BMS-ready
HVAC Panel
View more
8000 A · Dual bus
Double Busbar Panel
View more
MLTP · Incomer + outgoings
Main LT Panel
View more
APFC · Detuned · 0.99
Capacitor Panel
View more
Fitted with
The assembly is ours; the switchgear inside it is genuine, authorised-channel product from the makes you specify.
Next step
Send us the single-line.
A drawing, a load list or a BOQ is enough to start. You'll get the ratings checked against the actual fault level, a general-arrangement drawing to approve, and a fixed price.
